Product Description
Some pumps do not lend themselves to direct drive control with the WaveEngine due to cabling or other restrictions, but many of these pumps do offer 0-10V controllability. This 0-10V HYDROS WaveEngine Quad Cable supplies four independent 0-10V outputs to control these pumps.
Broad Compatibility
Make pumps from different manufacturers work together to provide a single, integrated flow management system. You can now use a VorTech™ MP40WQD at one end of your tank and a Reef Octopus Octo Pulse 4 at the other end of the tank and have them work together simultaneously, opposite each other or completely different. Best of all, it isn’t limited to two pumps! Add a Maxspect Gyre into the pattern if you want too.
Do you have a controllable return pump or skimmer? Bring them to the party because the HYDROS WaveEngine will control them too!
Clutter Reduction
The clutter of power bricks, cables and controllers is becoming an increasing problem for reef keepers. The four pump driver outputs on the HYDROS WaveEngine replace the pump controller, power supplies and any necessary external wireless control modules. Best of all, the HYDROS WaveEngine can run four pumps off a single power supply!
Needless to say, it is easy to install. Simply toss out your existing power supplies and controllers, connect the HYDROS WaveEngine and you’re ready to start moving water.
0-10V INPUT Control
Control any pump via variable speed INPUT. Unlike other controllers that require intricate programming on pumps connected via 0-10V, the HYDROS WaveEngine allows 0-10V INPUT connected Pumps to take full advantage of all native flow modes and presets without complicated coding.
Reverse Pump Drive
Some pumps can provide additional pattern options by running in reverse. For example, the Reef Octopus Octo Pulse 4 changes from a highly directed flow to a gentle broad push if you run it in reverse. The HYDROS WaveEngine allows you to take advantage of Reverse Drive to further increase the available flow patterns.
Cross Engine Synchronization
Multiple HYDROS WaveEngines can be used to control even larger number of pumps and the patterns will remain perfectly synchronized. A pump connected to HYDROS WaveEngine “A” will run in perfect synchronization with a pump connected to HYDROS WaveEngine “B”.
Remote Access
A FREE and easy to use iOS and Android compatible app allows you to control everything including flow modes, schedules, pump configuration, as well as monitor performance. You will have no problem with connection because the app can run in cloud mode or local mode.
Cloud mode allows you to communicate with your HYDROS WaveEngine when an internet connection is available. The HYDROS WaveEngine system is part of the Amazon Web Services (AWS) and Internet of Things (IoT) platform, guaranteeing high security and reliability.
Local control gives you the option of direct access to your control settings in the event your internet connection is unavailable. No matter your situation, the HYDROS WaveEngine will work to keep your tank alive!
Battery Backup
An optional battery backup system (sold seperately) is available so that the HYDROS WaveEngine will move into more energy-efficient patterns (defined by you) to allow circulation to continue through the power failure automatically.
Real-Time Monitoring and Notifications
You can set up text message alerts and/or emails to be notified if a pump is blocked or disconnected. If total power failure takes place at your home, bringing down your entire tank and internet connection, you will still be notified via email or text.
Do your pumps ever get dirty and drop in performance?
The HYDROS WaveEngine will monitor the power being consumed by each pump along with its shaft RPM and will notify you if the pump’s performance is suffering and may require maintenance.
Third Party Integration
The HYDROS WaveEngine is compatible with 3rd party controllers such as the Neptune Systems APEX, the Reef Angel, GHL Profilux and others via the 0-10V control port.
- Control Pump Speeds
- Trigger Flow Mode Changes
Splash Proof Enclosure
The HYDROS WaveEngine is sealed in a watertight case with industrial splash proof connectors for safe and long-lasting operation. Why would it not be if intended for aquarium use?
Hydros Compatible Pumps |
|||
Make and Model |
Direct ConnectConnect directly to the pump removing the clutter of the power brick and the controller |
0-10V Pump InputThe Hydros WaveEngine supplies four independent 0-10V outputs to control these pumps |
Wireless RF ControlledEcoTech Marine Vortech pumps can be controlled using their wireless "slave" mode |
| Maxspect Gyre XF130 / XF230 |
✓ | - | - |
| Maxspect Gyre XF150 / XF250 |
- | - | |
| Maxspect Gyre XF330 / XF350 |
✓ | - | - |
| Maxspect Gyre XF280 |
✓ | - | - |
| IceCap Gyre 1K & 3K |
✓ | - | - |
| IceCap Gyre 2K & 4K |
✓ | ✓ | - |
| Reef Octopus VarioS-2 & VarioS-4 |
✓ | ✓ | - |
| Reef Octopus VarioS-6 & VarioS-8 |
- | ✓ | - |
| Reef Octopus Octo Pulse 2 & Pulse 4 |
✓ | ✓ | - |
| Abyzz A100, A200, A400, A1200 |
- | ✓ | - |
| Abyzz AFC 400 |
- | ✓ | - |
| Aqua Illumination Nero 5 |
- | - | - |
| CoralBox QP-9+ & 16+ |
- | ✓ | - |
| Current USA eFlux |
- | - | - |
| EcoTech Marine Vortech MP10WQD, MP40WQD, MP60WQD |
- | - | ✓ |
| Jebao WP, RP, PP, FS and SW Series |
- | ✓ | - |
| Skimz | - | - | - |
| Tunze Turbelle Nanostreams |
- | ✓ | - |
| Waveline DC 6000 & 10000II |
- | ✓ | - |
